SG3428MP - Omada SG3428MP 24 Port Gigabit PoE+ L2 Managed Switch with 4x SFP Ports
Omada

SG3428MP - Omada SG3428MP 24 Port Gigabit PoE+ L2 Managed Switch with 4x SFP Ports

SKU: SG3428MP ● In Stock
$778.00
Free shipping over $299 Genuine product 7-day returns
  • ✅ 24× Gigabit 802.3af/at PoE+ ports and 4× Gigabit SFP slots
  • ✅ 384 W total PoE budget with up to 30 W PoE output per port
  • ✅ Centralized cloud management via the web or the Omada app
  • ✅ Standalone management via web, CLI, SNMP, and RMON
  • ✅ Static Routing helps route internal traffic for higher efficiency
  • ✅ VLAN, ACL, QoS, IGMP Snooping, OAM, and DDM
  • ✅ ERPS supports rapid protection and recovery in a ring topology
  • ✅ Durable metal casing and rack-mountable design
TP-Link | Omada L2+ managed switches provide high performance, powerful L2 and L2+ features like static
routing, enterprise-level QoS, advanced security strategies and a bundle of ISP features. The IP-MAC-Port
Binding (IMPB) and Access Control List (ACL) functions protect against broadcast storm, ARP and Denial-ofService (DoS) attacks, etc. Quality of Service (QoS, L2 to L4) provides enhanced traffic management capabilities to move your data smoother and faster. The OAM and DDM functions help facilitate network management. Moreover, the easy-to-use web management interfaces, along with CLI, SNMP and Dual Image mean faster setup and configuration with less downtime. TP-Link | Omada L2+ managed Switches provide a reliable, secure solution for enterprise, campus and ISP networks.

Technical Specifications

Switch type Managed
Switch layer L2+
Quality of Service (QoS) support Y
Web-based management Y
Cloud-managed Y
ARP inspection Y
Configuring Location Settings (CLI) Y
System event log Y
Basic switching RJ-45 Ethernet ports quantity 24
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity 24
SFP module slots quantity 4
Console port RJ-45/Micro-USB
Power connector AC-in jack
Networking standards IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3i,IEEE 802.3u,IEEE 802.3z
10G support N
Copper ethernet cabling technology 10BASE-T,1000BASE-T
Port mirroring Y
IP routing Y
Flow control support Y
Link aggregation Y
Broadcast storm control Y
Rate limiting Y
Spanning tree protocol Y
Head-of-line (HOL) blocking Y
Ethernet LAN data rates 10,100,1000
Active link detection Y
VLAN support Y
Virtual LAN features MAC address-based VLAN,Port-based VLAN,Private VLAN,Tagged VLAN,Voice VLAN
Number of VLANs 4000
Switching capacity 56
Forwarding rate 41.66
MAC address table 16000
Store-and-forward Y
Jumbo frames support Y
Jumbo frames 9000
Packet buffer memory 12
DHCP features DHCP client,DHCP relay,DHCP server,DHCP snooping,DHCPv6 client,DHCPv6 snooping
Access Control List (ACL) Y
IGMP snooping Y
Security algorithms SSH,SSL/TLS
MAC address filtering Y
Static port security Y
SSH/SSL support Y
Loop protection Y
BPDU filtering/protection Y
IP-MAC-Port binding Y
Authentication MAC-based authentication,Port-based authentication
Multicast support Y
Management protocols SNMPv1/v2c/v3, LLDP/LLDP-MED
GARP VLAN Registration Protocol (GVRP) Y
Rack mounting Y
Form factor 1U
Product colour Black
LED indicators Y
Number of fans 2
Export Control Classification Number (ECCN) EAR99
Power source AC
Power supply included Y
AC input voltage 100 - 240
AC input frequency 50/60
Power consumption (max) 480.1
Power over Ethernet (PoE) Y
Power over Ethernet plus (PoE+) ports quantity 24
Power over Ethernet (PoE) power per port 30
Total Power over Ethernet (PoE) budget 384
Operating temperature (T-T) 0 - 45
Storage temperature (T-T) -40 - 70
Operating relative humidity (H-H) 10 - 90
Storage relative humidity (H-H) 5 - 90
Heat dissipation 1637.14
Width 440
Depth 330
Height 44
Quick start guide Y
User guide Y
Certification CE, FCC, RoHS
