STARTECH.COM 3M DISPLAYPORT 1.4 EXTENSION CABLE, DP 1.4, 8K 60HZ, LTW

SKU: 10F-DP14-EXTEND-CBL ● In Stock
$73.00
Free shipping over $299 Genuine product 7-day returns
  • ✅ DP 1.4 EXTENSION: Extend a 8K 60Hz / 4K 144Hz DisplayPort connection for greater versatility using this DP 1.4 Extension Cable; Choose the right cable at-a-glance with performance markings on connectors for quick identification
  • ✅ FULL-FEATURED DISPLAYPORT 1.4: Supports 32.4Gbps bandwidth for superior UHD performance; Up to 4K 144Hz for ultra-smooth visuals; Connects to UHD monitors, high performance GPUs, and dedicated video/media devices; Backward compatible with DP 1.2/1.1
  • ✅ QUALITY CONSTRUCTION: Durable Gold-plated connectors provide a precise fit to minimize wear and signal loss; Flexible TPE jacket with strain reliefs withstands frequent or static bends, for easy routing around corners and desk edges
  • ✅ APPLICATIONS: Swiftly extend the reach between DisplayPort devices; Suitable for video walls/mounted TVs, multi-monitor workstations, and DP switches/KVMs; Use this cable as a Port Saver to reduce strain on device ports; Ideal for hard-to-access DP ports
  • ✅ SPECS: Black; 10-foot (3-meter); Bi-directional; Passive; DisplayPort 1.4 supports 8K 60Hz/4K 144Hz w/HBR2, MST, and 32-ch audio; 32.4Gbps; 30AWG; 8.4mm (0.33in) O.D.; TPE Jacket is halogen-free and RoHS compliant
Extend a DisplayPort 1.4 connection or safeguard against port/connector strain

This high quality DisplayPort 1.4 Extension Cable provides extra reach for greater setup versatility, and reduces wear and tear of the DP port on your monitor or other devices. The connector markings enable quick visual identification, distinguishing this cable from other similar-looking or unmarked DisplayPort cables. Eliminate guesswork and always choose the appropriate cable to support full DP 1.4 performance.

Full DisplayPort Capability

This male-to-female DisplayPort extension cable supports all DisplayPort 1.4 features:

• Resolutions up to 8K 60Hz or 4K 144Hz
• High speeds with a bandwidth of up to 32.4Gbps
• Multi-Stream Transport (MST) for daisy-chaining multiple monitors
• High Dynamic Range (HDR) for higher contrast ratio and vivid colors
• Crystal-clear sound with up to 32 digital audio channels

This DisplayPort extension cable is backwards compatible with earlier versions of DisplayPort, ensuring seamless integration with existing DisplayPort devices.

Technical Specifications

Connector 1 form factor Straight
Connector 2 form factor Straight
Connector contacts plating Gold
DisplayPort version 1.4
Maximum resolution 7680 x 4320
Supported graphics resolutions 3840 x 2160,7680 x 4320
Maximum refresh rate 144
Cable length 3
Connector 1 DisplayPort
Connector 2 DisplayPort
Connector 1 gender Male connector
Connector 2 gender Female connector
Product colour Black
Cable material Copper
Cable shielding Aluminum mylar foil
Jacket material Thermoplastic Elastomer (TPE)
AWG wire size 30
High Dynamic Range (HDR) supported Y
Bandwidth 32400
Multi-Stream Transport (MST) Y
Fire-resistance rating VW-1
Operating temperature (T-T) 0 - 50
Storage temperature (T-T) -20 - 70
Operating relative humidity (H-H) 5 - 85
Compliance certificates CE,RoHS
Doesn't contain Halogen
Cable diameter 8.4
Weight 240
Package width 201
Package depth 187
Package height 39
Package weight 246
Master (outer) case width 500
Master (outer) case length 320
Master (outer) case height 210
Products per master (outer) case 40
