StarTech.com J9151A-BX-D-ST - SFP+ Module - J9151A-BX-D Comp - D/S
StarTech.com J9151A-BX-D-ST - SFP+ Module - J9151A-BX-D Comp - D/S
StarTech.com J9151A-BX-D-ST - SFP+ Module - J9151A-BX-D Comp - D/S
StarTech.com

StarTech.com J9151A-BX-D-ST - SFP+ Module - J9151A-BX-D Comp - D/S

SKU: J9151A-BX-D-ST ● In Stock
$55.34
Free shipping over $299 Genuine product 7-day returns

StarTech.com J9151A-BX-D-ST - SFP+ Module - J9151A-BX-D Comp - D/S

Overview

10 Gbps | Single Mode Fiber | LC | 10 km (6.2 mi) | Lifetime Warranty

The J9151A-BX-D-ST is an HPE J9151A-BX-D compatible downstream fiber SFP+ transceiver which pairs with StarTech.com's J9151A-BX-U-ST. They are designed, programmed and tested to work with 10GBASE-BX compatible MSA switches and routers. The SFP+ transceiver module supports a maximum distance of up to 10 km (6.2 mi) and delivers dependable 10 GbE connectivity over fiber cabling.

Technical Specifications:

• Wavelength: 1330nmTx/1270nmRx
• Maximum Data Transfer Rate: 10Gbps
• Type: Single Mode Fiber
• Connection Type: LC Connector
• Maximum Transfer Distance: 10 km (6.2 mi)
• Power Consumption:
• DDM: Yes

This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP+ modules and direct-attach SFP+ Cables, providing the convenience and reliability you need to ensure dependable network performance.

  • 100% HPE J9151A COMPATIBLE: 10 Gigabit Ethernet BiDi Fiber Single Strand SFP+ works with HPE switches like 2920, 2910al, 3500yl, 3800, 5400zl and others
  • INCREASE BANDWIDTH ON EXISTING INFRASTRUCTURE: This 10 Gigabit Ethernet bi-directional WDM SFP+ transceiver module sends and receives over a single strand of fiber optic cable instead of two
  • TECHNICAL SPECS: 10GBASE-BX / 10Gbps / 10G Bi-Directional Downstream / Single Mode (SMF) / LC Connector / 1330nmTx/1270nmRx / Digital Diagnostic Monitoring (DDM) / Distances up to 10km (6.2mi)
  • PROGRAMMED & TESTED FOR COMPATIBILITY: Compatible with OEM routers and switches. MSA Compliant with DDM that reports the transceiver's status to most SNMP network management tools
  • THE IT PRO’S CHOICE: Designed and built for IT Professionals, this SFP module is backed for life (lifetime of module, not network switch), including free lifetime 24/5 multi-lingual technical assistance

Technical Specifications

SFP transceiver type Fiber optic
Maximum data transfer rate 10000
Interface type SFP+
Single-mode fiber (SMF) supported Y
Multi-mode fiber (MMF) supported N
Fiber optic connector LC
SFP transceiver standard BX
Maximum transfer distance 10000
Tx wavelength (max) 1330
Rx wavelength (max) 1270
Digital Diagnostics Monitoring (DDM) Y
Product colour Silver
Hot-swap Y
Mean time between failures (MTBF) 646156559
Brand compatibility HP
Compatible products J9151A
Power consumption (typical) 1.3
Width 58.4
Depth 13.9
Height 12.6
Weight 24
Quantity per pack 1
Package width 96
Package depth 114
Package height 34
Package weight 50
Master (outer) case width 206
Master (outer) case length 306
Harmonized System (HS) code 85369010
Master (outer) case height 260
Products per master (outer) case 25
