TP-Link
TP-Link TL-SG116P - TP LINK 16-Port Gigabit Desktop Switch with 16-Port PoE+
$199.54
Free shipping over $299
Genuine product
7-day returns
TP-Link TL-SG116P - TP LINK 16-Port Gigabit Desktop Switch with 16-Port PoE+
- With 16 PoE+ ports, transfers data and power on one single cable
- Compliance with IEEE 802.3af/at PoE+, the switch supports PoE Power up to 30 W for each PoE port
- Supports PoE Power up to 120 W for all PoE ports*
- Up to 250 m data and power transmission range under Extend Mode**
- Priority Mode ensures high priority of ports 1–4 to guarantee the quality of the sensitive applications
- Isolation Mode allows one-click client traffic separation for higher security and performance
- Automatically reboots your dropped or unresponsive PoE-powered devices with PoE Auto Recovery
- Plug and play with no configuration required
Technical Specifications
| Switch type | Unmanaged |
|---|---|
| Quality of Service (QoS) support | Y |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 16 |
| Networking standards | IEEE 802.1Q,IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3u |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
| Cable types supported | Cat3,Cat4,Cat5,Cat5e,Cat6 |
| Port mirroring | Y |
| Full duplex | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Rate limiting | Y |
| Auto MDI/MDI-X | Y |
| Auto-negotiation | Y |
| Cable length detection | Y |
| VLAN support | Y |
| Virtual LAN features | Protocol-based VLAN,Tagged VLAN |
| Number of VLANs | 32 |
| Switching capacity | 32 |
| Forwarding rate | 23.81 |
| MAC address table | 8000 |
| Store-and-forward | Y |
| Number of queues | 4 |
| Jumbo frames support | Y |
| Jumbo frames | 9000 |
| Packet buffer memory | 4.1 |
| IGMP snooping | Y |
| Loop protection | Y |
| Stackable | Y |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Y |
| Wall mountable | Y |
| Power supply included | Y |
| AC input voltage | 220 |
| AC input frequency | 50 |
| DC input voltage | 9 |
| Input current | 0.6 |
| Power consumption (typical) | 11.72 |
| Power consumption (max) | 144.28 |
| Power over Ethernet (PoE) | Y |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -40 - 70 |
| Operating relative humidity (H-H) | 10 - 90 |
| Storage relative humidity (H-H) | 5 - 90 |
| Heat dissipation | 490.55 |
| Width | 286 |
| Depth | 111.7 |
| Height | 25.4 |
| Quick start guide | Y |
| Package width | 227 |
| Package depth | 434 |
| Package height | 70 |
| Package weight | 2000 |
🚚 7-Day Returns Policy
Not happy? Return within 7 days of delivery for a full refund or exchange. Items must be unused and in original packaging. Contact contact@kwtech.co.nz to arrange.
| Brand | TP-Link |
|---|---|
| Product Type | B2B - Networking & Routing |
| Weight | 0.5 kg |
Shipping Information
- Free NZ-wide shipping on orders over $299
- Standard delivery 2–5 business days
- Rural delivery may take an additional 1–2 days
- Same-day dispatch for orders placed before 2pm (weekdays)
Returns Policy
- 7-day returns on unused items in original packaging
- Faulty or damaged products covered under warranty
- Contact our support team to initiate a return
You May Also Like
Panorama Antennas
Panorama Antennas DMM4-6-60-2SP - 4G/5G 4x4 MiMo Antenna Desk/Window/Wall Mount
