Tycon Systems
Tycon Systems TP-VRHP-2424 - Tycon Power Systems TP-VRHP-2424
$75.00
Free shipping over $299
Genuine product
7-day returns
TP-VRHP-2424
Tycon Systems TP-VRHP-2424 - Tycon Power Systems TP-VRHP-2424
Description
The Tycon Power TP-VRHP-2424 is a 70W voltage converter/regulator which accepts an input of plus or minus 18VDC to 36VDC and provides a regulated output of 24VDC @ 2.9A 70W. These units are perfect for providing stable regulated 24VDC voltage from 24VDC battery banks. Input and outputs are wire terminals for wire up to 12AWG. Operates from -30 to +65 deg C.
Features
- High Output, Short Circuit Protected
- Metal Enclosure, DIN rail mounting
- Industrial Temperature Operation
- Most Models Isolated Input to Output
- Great for Security Systems, Remote Power Systems, Wireless Base Stations
Specifications
| Details | |
|---|---|
| Manufacturer's Product Code | TP-VRHP-2424 |
| DC Input Voltage | 18-36VDC |
| DC Output Voltage | 24VDC @ 2.9A |
| Output Power (max) | 70W |
| Dimensions (LxWxH) | 102x57x32mm |
| Brand | Tycon Systems |
|---|---|
| Product Type | Networking & Wireless |
| Weight | 0.5 kg |
