EATON 5E900UIAU - 5E GEN 2 UPS 900VA/480W Line Interactive Tower
Features
Eaton 5E Gen 2 900VA/480W 2 x ANZ Outlets Line Interactive Tower UPS
The Eaton 5E Gen2 UPS combines proven high performance and quality with affordable pricing to offer cost-effective, reliable protection against power outages and bad power quality. Suitable for home use or for equipment in small business and professional environments, this latest version of our 5E line interactive UPS now also offers national outlets flexibility plus the convenience of permanently recharged batteries (even when off) and the ability to start without mains power (cold start).
CE certification by the external TUV agency guarantees compliance with the latest international safety standards.
Easy Application Connection And Protection:
A perfect fit for any local plug type thanks to national outlet formats. Eaton's 5E Gen2 UPS offers single-product simplicity in multiple residential and commercial environments.
Greater Tolerance Of Grid Fluctuations:
All kinds of influences can upset grid voltage at any time. Features double-boost line interactive topology (AVR) for wider input voltage window (under and overvoltage: 140 - 300 V) to save battery power in the event of power outage.
Silent Operation For A Better Customer Experience:
A key consideration in residential settings to ensure peace of mind as noisy equipment can distract - as well as add to stress levels. Thanks to a fanless design on all models up to 1200 VA, the 5E Gen2 UPS guarantees silent operation.
Specifications
Technical Specifications
| PRODUCT NAME | Eaton 5E Gen2 UPS |
|---|---|
| CATALOG NUMBER | 5E900UIAU |
| PRODUCT LENGTH/DEPTH | 288 mm |
| PRODUCT HEIGHT | 148 mm |
| PRODUCT WIDTH | 100 mm |
| PRODUCT WEIGHT | 5.29 kg |
| COMPLIANCES | RoHS DirectiveLVD DirectivePackaging DirectiveWEEE DirectiveBatteries DirectiveEMC DirectiveCB |
| CERTIFICATIONS | IEC/EN 62040-3IEC/EN 62040-1IEC/EN 62040-2CEEACUKCACmUkrRCM |
| SECONDARY FREQUENCY - MAX | 60 Hz |
| WATTAGE | 480 W |
| FORM FACTOR | Tower |
| INCLUDES NETWORK CARD | No |
| INPUT CONNECTION | AU plug |
| INPUT VOLTAGE - MIN | 140 V |
| OUTPUT VOLTAGE - MAX | 257 V |
| SECONDARY FREQUENCY - MIN | 50 Hz |
| SOFTWARE COMPATIBILITY | Eaton UPS Companion (enables safe system shutdown, energy usage metering and configuration of UPS settings) |
| BATTERY TYPE | Sealed, lead-acid |
| EFFICIENCY | 95 |
| SPECIAL FEATURES | Automatic Voltage Regulation (AVR)Saves space with a compact tower designHID-compliant USB port, for automatic integration with major operating systems (Windows/Mac OS/Linux) |
| CONSTRUCTION TYPE | Free standing model |
| OUTPUT VOLTAGE - MIN | 195 V |
| COLOR | Black |
| EXTENDED BATTERY CAPABILITY | No |
| OUTPUT VOLTAGE RANGE | 195-257 V |
| TOPOLOGY | Line-interactive |
| SURGE PROTECTION | Yes |
| INPUT NOMINAL VOLTAGE | 240V |
| INPUT FREQUENCY RANGE | 45-65 Hz |
| INTERNAL BYPASS | No |
| INPUT VOLTAGE - MAX | 300 V |
| VOLTAGE TYPE | AC |
| PHASE (OUTPUT) | 1 |
| BATTERY MANAGEMENT | Automatic battery test, deep-discharge protection, cold-start capable |
| AUTO SHUTDOWN FUNCTION | Yes |
| NUMBER OF OUTPUTS C13 | 2 |
| OPERATING TEMPERATURE - MIN | 0 °C |
| VA RATING | 900 VA |
| POTENTIAL FREE SWITCH CONTACT | No |
| RECEPTACLE | (2) AU |
| PHASE (INPUT) | 1 |
| PACKAGE CONTENTS | Quick startSafety instructions |
| NOISE LEVEL | <25 dB at 1 meter |
| FEED TYPE | 1 |
| RUNTIME GRAPH | View runtime graph |
| USER INTERFACE | LEDs |
| BATTERY QUANTITY | 1 |
| OPERATING TEMPERATURE - MAX | 40 °C |
| VOLTAGE | 240V |
| HOT SWAP POWER | No |
| TEMPERATURE RANGE | 0° to 40°C (32° to 104°F) |
| ETHERNET INTERFACE | No |
| COMMUNICATION | USB port (HID compliant) |
| RELATIVE HUMIDITY | 0-85% non-condensing |
| OUTPUT APPARENT POWER | 900 VA |
| RACK MOUNTING KIT | No |
| OUTPUT FREQUENCY | 50/60 Hz |
| TYPE OF INTERFACE | USB |
| PRIMARY FREQUENCY - MIN | 45 Hz |
| BATTERY RATING | 12 V / 9 Ah |
| TYPE | UPS |
| OUTPUT NOMINAL VOLTAGE | 240V |
| INPUT VOLTAGE RANGE | 140-300 V |
| NOMINAL FREQUENCY | 50/60 Hz |
| PRIMARY FREQUENCY - MAX | 65 Hz |
| Brand | EATON |
|---|---|
| Product Type | Power & Charging > UPS & Power Distribution > UPS |
| Weight | 2.404 kg |
| Warranty |
|---|
