StarTech.com 127B-USBC-MULTIPORT - USB C Multiport Adapter 4K 60Hz HDMI PD
Features
6-IN-1 USB-C HUB
This USB C multiport adapter features 4K 60Hz HDMI (HDR10), 3x USB-A 3.2/3.1 Gen 1 (5Gbps), Gigabit Ethernet, Shared USB-C Power/USB 2.0 Data with 100W USB Power Delivery Pass-Through
4K 60HZ HDMI VIDEO WITH DP 1.4 ALT-MODE
USB-C Multiport Adapter features HDMI 4K 60Hz (HDR) uncompressed video; Ideal for high-quality presentations/image files for office, boardroom or work from home applications; 4K 30Hz on DP 1.2 Alt-Mode host devices
EXTRA LONG CABLE
12" (30 cm) attached cable for extended reach to reduce port/connector strain on 2-in-1 devices like Surface Pro 7/8, iPad Pro, HP Elite x2/laptops on riser stands; Ideal for on-the-go travel use in office/home office/shared workspaces
RELIABLE PERFORMANCE
USB bus powered or via external USB-C power adapter; 100W Power Delivery 3.0 pass through w/ 15W reserved for adapter to avoid video flickering, device dropouts or overdrawing power common in other hubs; Up to 85W for laptop charging
COMPATIBILITY
Mini dock is compatible with USB-C laptops, Ultrabooks and Chromebooks, and Thunderbolt 3/4 laptops from HP, Dell, Lenovo; MacBooks (Intel & M1 Pro/Max processors) and Surface; works with Windows, macOS, iPadOS, Android, Linux & Chrome OS
CONNECTIVITY TOOLS
Provided with the portable all-in-one USB Type C docking station adapter, this application improves performance and security; Featuring USB Event Monitoring & Windows Layout utilities
Specifications
Technical Specifications
| External Ports | 1 - HDMI (19 pin)3 - USB 3.2 Type-A (9 pin, Gen 1, 5Gbps)1 - RJ-451 - USB Type-C (Power Delivery + Data, 24 Pin, 480Mbps) |
|---|---|
| Host Connectors | 1 - USB 3.2 Type-C (24 pin, Gen 1, 5Gbps) |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Storage Temperature | -10°C to 70°C (14°F to 185°F) |
| Humidity | 5~90% RH (Non-condensing) |
| 4K Support | Yes |
| Fast-Charge Port(s) | No |
| Displays Supported | 1 |
| Interface | USB 3.2 Gen 1 |
| Bus Type | USB-C |
| Industry Standards | HDMI 2.0,HDR10DisplayPort 1.4USB 3.2 Gen 1 (5Gbps)USB Power Delivery Specification Rev. 3.0IEEE 802.3IEEE 802.3uIEEE 802.3ab |
| Chipset ID | VIA - VL102VIA - VL817Realtek - RTL8153Realtek - RTD2172ATerminus Tech - FE1.1S |
| LED Indicators | 1 - Network Connection LED (Green) - Solid Indicates Active Network Connection1 - Network Activity LED (Amber) - Blinking Indicates Network Data Transfer |
| Package Length | 14,2 cm [5,6 in] |
| Package Width | 17,0 cm [6,7 in] |
| Package Height | 3,0 cm [1,2 in] |
| Shipping (Package) Weight | 200,0 g [7,1 oz] |
| Maximum Data Transfer Rate | 5Gbps |
| Maximum Digital Resolutions | DisplayPort 1.416:9 Aspect Ratio: 4096x2160 60Hz21:9 Aspect Ratio: 3440x1440 60HzDisplayPort 1.216:9 Aspect Ratio: 4096x2160 30Hz21:9 Aspect Ratio: 3440x1440 30Hz |
| Type and Rate | USB 3.2 Gen 1 - 5 Gbit/s |
| UASP Support | Yes |
| Compatible Networks | 10/100/1000 Mbps |
| PXE | Yes |
| Full Duplex Support | Yes |
| Color | Space Gray |
| Product Length | 5,0 cm [2,0 in] |
| Product Width | 42,7 cm [16,8 in] |
| Product Height | 1,2 cm [0,5 in] |
| Weight of Product | 70,0 g [2,5 oz] |
| Material | Aluminum |
| Power Source | Bus Powered and Host USB-C Power Adapter |
| Power Delivery | 100W |
| Power Consumption (In Watts) | 15W |
| Brand | StarTech.com |
|---|---|
| Product Type | Computers & Tablets > Docking Stations |
| Weight | 0.059 kg |
| Warranty |
|---|
