Ubiquiti UniFi Access Reader G3 with Apple Touch Pass Support

Ubiquiti

Ubiquiti UniFi Access Reader G3 with Apple Touch Pass Support

Name: Ubiquiti UniFi Access Reader G3 with Apple Touch Pass Support
Brand: Ubiquiti
SKU: UA-G3-W
Price: 385.99 NZD
Availability: InStock

SKU: UA-G3-W ● In Stock

$335.64

inc GST ▲ +GST

Free shipping over $299 Genuine product 7-day returns

Features

G3 Reader

Compact third-generation access reader with Apple Touch Pass support.

- Unlock with an NFC card, UniFi Identity mobile app, or Touch Pass*
- Supports hand-wave unlocking as a request-to-exit device
- Provides entry and exit greeting messages
- IP55-rated weather resistance (-30 to 45°C)
- Connects to UniFi Access Hub via PoE

Specifications

Technical Specifications

Dimensions	93 x 40 x 36.5 mm (3.7 x 1.6 x 1.4")
Weight	82 g (2.9 oz)
Enclosure material	Polycarbonate, glass
Mounting material	Aluminum alloy
Mounting	In wall, gang box
Weatherproofing	IP55
Networking interface	(1) 10/100 MbE RJ45 port
Connectivity	BLE 4.1NFC
Power method	PoEUL 294 Power-limited Class 2 PSUUL 60950-1/62368-1 LPS/PS2 PSU
Supported voltage range	48V DC
Max. power consumption	5W
ESD/EMP protection	Air: ±15kV, contact: ±8kV
Sensors	Proximity sensor
Speaker	(1) 8 ohm, 0.7W
LEDs	R/G/B/W
Button	(1) Factory-reset
NFC frequency	13.56 MHz
NFC read range	< 30 mm
NFC technology	ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340)MIFARE Classic / MIFARE DESFIRESony FeliCa™ (ID only)NFC Forum tags T1T, T2T, T3T, T4T and T5TECP 2.0
Operating environment	Outdoor use
Ambient operating temperature	-30 to 45° C (-22 to 113° F)
Ambient operating humidity	5 to 90% noncondensing
Software information	The software version of a product can be checked athttps://unifi.ui.com
UL 294 level	Destructive attack: Level ILine security: Level IEndurance: Level IStandby power: Level I
UL 294 statement	Compliance with IEEE 802.3 specifications was not verified as part of UL 294.The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.
PoE cabling requirements	Cable 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site.The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm 2 ) for patch cords; 24 AWG (0.21 mm 2 ) for horizontal or riser cable.
CAN/ULC-60839-11-1	Grade Grade assignment: I
Certifications	CE, FCC, IC, UL 294, CAN/ULC-60839-11-1
Document number, and issue date and/or revision level	UA-G3, V01
Management application	UniFi Access: Version 3.0.15 and later
