APC METERED VERTICAL PDU, 230V, 16A, 3.7KW, C13(18), C19(2), IEC-309, 2YR
APC METERED VERTICAL PDU, 230V, 16A, 3.7KW, C13(18), C19(2), IEC-309, 2YR
APC METERED VERTICAL PDU, 230V, 16A, 3.7KW, C13(18), C19(2), IEC-309, 2YR
APC

APC METERED VERTICAL PDU, 230V, 16A, 3.7KW, C13(18), C19(2), IEC-309, 2YR

SKU: AP8858EU3 ● In Stock
$1,528.48
Free shipping over $299 Genuine product 7-day returns
APC Metered Rack PDUs offer resilient power distribution and actively measure, display, and log volts, amps, real power (kW) & energy (kWh). This PDU offers LCD display, real-time remote monitoring and user-defined alarms to help prevent circuit overloads that can cause accidental power loss to critical equipment. Historical reporting enables users to meter customer power usage, optimize energy use as well as plan for capacity . This zeroU PDU can operate at up to 60 degrees Celsius and can be accessed, configured, and managed remotely via EcoStruxure IT, Web, SNMP and Command Line Interface. Power is supplied to the PDU at 220-240 volts via IEC 309 2P + E plug with a 3m (10 ft) cord while power comes out at 230 volts through (18) C13 and (2) C19 locking outlets. It integrates with EcoStruxure IT, and daisy-chaining is supported to monitoring up to 4 PDUs from 1 IP address as well as a local USB port for easy local firmware updates As a Green Premium product, this unit comes with a verified product environment profile, including carbon footprint, scope 3 emissions and end of life instructions.

Technical Specifications

PDU types Metered
Rack capacity 0U
Mounting Vertical
AC outlets quantity 20
Power plug IEC309
AC outlet types C13 coupler,C19 coupler
Input connection type IEC 309 16A 2P+E
Output connections 18x IEC 320 C13 2x IEC 320 C19
Cable length 3
Monitoring Current,Power,Voltage
AC input frequency 50 - 60
Nominal output voltage 230
Load capacity 3680
Maximum input current per phase 16
Maximum total current draw per phase 16
Maximum power 3680
Certification CSA C22.2 No. 60950,IEC 60950,METI Denan,UL 60950-1,VDE RoHS, REACH
Operating temperature (T-T) 5 - 45
Storage temperature (T-T) -25 - 65
Operating relative humidity (H-H) 5 - 95
Storage relative humidity (H-H) 5 - 95
Width 56
Depth 44
Height 902
Weight 2930
Package weight 4920
Package width 162
Package depth 107
Package height 1124
Total carbon footprint (kg of CO2e) 13349.44
