RB1100Dx4 - MikroTik RouterBOARD 1100Dx4 with AL21400 Cortex A15 CPU (4-cores, 1.4GHz per core), 1GB RAM, 13xGbit LAN, 60GB M.2 drive, RouterOS L6, 1U rackmount case, Dual PSU
MikroTik

RB1100Dx4 - MikroTik RouterBOARD 1100Dx4 with AL21400 Cortex A15 CPU (4-cores, 1.4GHz per core), 1GB RAM, 13xGbit LAN, 60GB M.2 drive, RouterOS L6, 1U rackmount case, Dual PSU

SKU: RB1100Dx4 ● In Stock
$789.00
Free shipping over $299 Genuine product 7-day returns

RB1100Dx4

RB1100Dx4 - MikroTik RouterBOARD 1100Dx4 with AL21400 Cortex A15 CPU (4-cores, 1.4GHz per core), 1GB RAM, 13xGbit LAN, 60GB M.2 drive, RouterOS L6, 1U rackmount case, Dual PSU

Description

The MikroTik RB1100AHx4 Dude Edition has Annapurna Alpine AL21400 CPU with four Cortex A15 cores clocked at 1.4Ghz each, for a maximum throughput of up to 7.5Gbit. The device supports IPsec hardware acceleration and are faster at it than any previous RouterBORD device (up to 2.2Gbps with AES128). The RB1100Dx4 comes in a 1U rackmount case and includes 13x Gigabit Ethernet ports, RS232 serial port and dual redundant power supplies (with -48v DC telecom power and 802.3at/af support). The RB1100AHx4 Dude edition features several high speed storage connectors (two SATA and two M.2) for using a Dude database, proxy cache or any other storage intensive feature. It includes a 60GB M.2 drive already installed.
Features
  • Quiet passive cooling
  • DC telecom power connector for -48V DC powering
  • IPsec hardware acceleration

Specifications

Details
Product code RB1100Dx4
CPU nominal frequency 1.4 GHz
CPU core count 4
Size of RAM 1GB
10/100/1000 Ethernet ports 13
PoE In Yes, 20V - 57V (-48V supported)
Voltage Monitor Yes
PCB temperature monitor Yes
Dimensions 444 x 148 x 47 mm
Operating System RouterOS
License level 6
Current Monitor Yes
Max Power consumption 25W
Serial port RS232
