UDB-Pro-Sector - Ubiquiti UniFi Device Bridge Pro Sector

UDB-Pro-Sector

UDB-Pro-Sector - Ubiquiti UniFi Device Bridge Pro Sector

Ubiquiti UniFi Device Bridge Pro Sector, 5 GHz point-to-multipoint access point that wirelessly bridges 50+ Device Bridge Pro clients at 5+ km distances.

Incredible Link Distances, deliver stable, high-capacity connectivity up to 5+ km (3.1 mi)—ideal for campuses, warehouses, and multi-site deployments without the cost of fiber trenching.

Plug-and-Play Installation, no complex setup, just plug in and enjoy reliable point-to-point connectivity.

Weatherproof Operation, IP-rated enclosure ensures consistent performance in harsh outdoor conditions.

Details
Manufacturer's Product Code	UDB-Pro-Sector
Dimensions	360.9 x 129.6 x 71.4 mm (14.2 x 5.1 x 2.8”)
WiFi Standard	WiFi 5
Spatial Streams	2
Coverage Area	5 km (3.1 mi)
Mounting Locations	Pole
Weatherproofing	IPX6
Power Method	PoE
MIMO	5 GHz: 2 x 2
Max. Data Rate	5 GHz: 400 Mbps (BW40)
Antenna Gain	5 GHz: 17 dBi
Max. TX Power	5 GHz: 25 dBm
Max. Conducted TX Power	25 dBm (Combined)
Supported Data Rates	802.11ac: (WiFi 5) 6.5 Mbps to 400 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40), 802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40), 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Wireless Security	WPA2 AES
Max. Power Consumption	6W
Supported Voltage Range	42.5—57V DC
Networking Interface	(1) GbE RJ45 port
Antennas	Internal
Management	Ethernet, WiFi
Channel Bandwidth	20/40 MHz
Wind Loading	128.2N at 200 km/h
Weight	Device: 782 g (1.7 lb), With mount: 835 g (1.8 lb)
Enclosure Material	UV-stabilized polycarbonate
Mount Material	UV-stabilized polycarbonate, stainless steel
Pole Mount Diameter	0.9—2.4" (24—60 mm)
Button	(1) Factory-reset
LEDs	System: Power, Ethernet
NDAA Compliant	Yes
Certifications	CE, FCC, IC
Operating Frequency	Worldwide: 5150 - 5875 MHz
Ambient Operating Temperature	-40 to 60° C (-40 to 140° F)
Ambient Operating Humidity	5 to 95% noncondensing
