Ubiquiti
UDB-Pro - Ubiquiti UniFi Device Bridge Pro with integrated UniFi WiFi Auto-Link
$444.34
inc GST ▲
+GST
Free shipping over $299
Genuine product
7-day returns
Features
5 GHz point-to-multipoint access point that wirelessly bridges 40+ Device Bridge Pro clients at 5+ km distances.
Specifications
Technical Specifications
| MIMO | 5 GHz2 x 2 |
|---|---|
| Max. Data Rate | 5 GHz400 Mbps (BW40) |
| Antenna Gain | 5 GHz17 dBi |
| Max. TX Power | 5 GHz25 dBm |
| Max. Conducted TX Power | 25 dBm (Combined) |
| Supported Data Rates | 802.11ac (WiFi 5)6.5 Mbps to 400 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40)802.11n6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Wireless Security | WPA2 AES (Always On) |
| Max. Power Consumption | 6W |
| Supported Voltage Range | 42.5-57V DC |
| Networking Interface | (1) GbE RJ45 port |
| Antennas | Internal |
| Management | EthernetWiFi |
| Wind Loading | 128.2N at 200 km/h |
| Weight | Device: 782 g (1.7 lb)With mount: 835 g (1.8 lb) |
| Mount Material | UV-stabilized polycarbonate, stainless steel |
| Enclosure Material | UV-stabilized polycarbonate |
| Pole Mount Diameter | 0.9-2.4" (24-60 mm) |
| Button | (1) Factory-reset |
| LEDs | SystemPower, Ethernet |
| Channel Bandwidth | 20/40 MHz |
| Certifications | CE, FCC, IC |
| NDAA Compliant | Yes |
| Operating Frequency | US/CA:U-NII-1 5150 - 5250 MHzU-NII-2A 5250 - 5350 MHzU-NII-2C 5470 - 5725 MHzU-NII-3 5725 - 5850 MHzWorldwide:5150 - 5875 MHz |
| Ambient Operating Temperature | -40 to 60° C (-40 to 140° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Brand | Ubiquiti |
|---|---|
| Product Type | Networking > Wireless Access Points |
| Weight | 1.23 kg |
| Warranty |
|---|
